6.2 Back Up Log Files (Service Terminal Interface only)
The Liebert AC8 maintains three types of logs—alarm, event and trend—that may be backed up to a
remote computer.
This feature is available only through the Service Terminal Interface.
To back up any of the alarm, event or trend logs:
1. Connect to the Liebert AC8 either from a remote computer or through the RS232 port (see
Connecting to the Service Terminal Interface on page111).
2. At the Main Menu, enter 9 (Backup Log Files).
3. At the Backup Log Files menu, as shown below, enter a number for the type of file you want to
back up:
• Enter 1 to back up the Alarm Log
• Enter 2 to back up the Event Log
• Enter 3 to back up the Trend Log for the first sensor (Sensor_1)
• Enter 4 to back up the Trend Log for the second sensor (Sensor_2)
• Enter 5 to back up the Trend Log for the third sensor (Sensor_3)
• Enter 6 to back up the Trend Log for the fourth sensor (Sensor_4)
Backup Log Files - Alarm Log File
BACKUP LOG FILES
Backup alarm, event and trend log files
1=BACKUP ALARM LOG FILE
2=BACKUP EVENT LOG FILE
3=BACKUP TREND LOG FILE-SENSOR_1
4=BACKUP TREND LOG FILE-SENSOR_2
5=BACKUP TREND LOG FILE-SENSOR_3
6=BACKUP TREND LOG FILE-SENSOR_4
7=RETURN TO MAIN MENU
SELECT A NUMBER:1
4. At the prompt to initiate a backup of the selected log file, enter Y (Yes - begin) or N (No -
cancel), then press Enter. The current setting appears in brackets—[N] in the following
example.
>INITIATE A BACKUP OF ALARM LOG-YES(Y) OR NO(N)?
>[N]
>[
NOTE: The following instructions refer to the Microsoft
®
Windows
®
HyperTerminal program. These
steps may vary for other communications programs.
5. At the top of the HyperTerminal window, shown below, click on Transfer, then on Receive File.
