State Description
OPERATING Device operating, or ON
STANDBY Device in standby mode
ALARM Device in alarm
FORCE ON Device forced ON by operator
FORCE OFF Device forced OFF by operator
HW FORCE ON Device forced ON by hardware switch
STAGED ON Device staged on by high sensor
EPOP OFF Device forced off by emergency power operation
PENDING Pending delay timer
NOT USED Device not used
Table 5.6
Digital output states
Viewing Additional Output Data
All output data may be viewed by scrolling beyond the four lines that appear on the LCD at one time:
• To view all outputs, use the arrows¯.
• To return to the previous screen, press the ESC key.
Vertiv | Liebert® AC8 User Manual | 44
