114 • Step-by-Step Guide to your own Linux Application
File System and Linux Kernel Update
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
An example for a Linux kernel update:
LFBK # run update-kernel
Station Address: 20:00:00:7B:FF:07
HW-MAC Address: 00:20:07b:00:07ff
Intel LXT97xA Ethernet located via MII
10Mbs - half duplex link established
TFTP from server 192.168.1.2; our IP address is 192.168.1.3
Filename 'linux.flashme'.
Load address: 0x40000
Loading
: #################################################
#################################################
#################################################
######################################
done
Bytes transferred = 1239096 (12e838 hex)
Un-Protect Flash Sectors 52-70 in Bank # 1
Erase Flash Sectors 52-70 in Bank # 1
Erasing sector 52 ... ok.
Erasing sector 53 ... ok.
Erasing sector 54 ... ok.
Erasing sector 55 ... ok.
Erasing sector 56 ... ok.
Erasing sector 57 ... ok.
Erasing sector 58 ... ok.
Erasing sector 59 ... ok.
Erasing sector 60 ... ok.
Erasing sector 61 ... ok.
Erasing sector 62 ... ok.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
