212 • Fieldbus Communication
ETHERNET
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
10.1.3.4 Administration and Diagnosis Protocols
In addition to the communication protocols described above, various fieldbus
specific application protocols and a view protocols for system admimnistration
and diagnosis can be implemented.
• BootP
• HTTP
• DHCP
• DNS
• SNTP
• FTP
• SMTP.
More information
You can find a list of the exact available implemented protocols in the chapter
"Technical Data" to the fieldbus coupler and/or controller.
10.1.3.4.1 BootP (Bootstrap Protocol)
The BootP protocol defines a request/response mechanism with which the
MAC-ID of a fieldbus node can be assigned a fix IP address.
For this a network node is enabled to send requests into the network and call
up the required network information, such as the IP address of a BootP server.
The BootP server waits for BootP requests and generates the response from a
configuration database.
The dynamic configuration of the IP address via a BootP server offers the user
a flexible and simple design of his network. The WAGO BootP server allows
any IP address to be easily assigned for the WAGO (programmable) fieldbus
coupler or controller. You can download a free copy of the WAGO BootP
server over the Internet at:
http://www.wago.com.
More information
The procedure for address allocation with the WAGO BootP Server is
described in detail in the Chapter “Starting up a Fieldbus Node”.
The BOOTP Client allows for dynamic configuring of the network
parameters:
Parameter Meaning
IP address of the client Network address of the (programmable) fieldbus
coupler or controller
IP address of the router If communication is to take place outside of the local
network, the IP address of the routers (gateway) is
indicated in this parameter.
Subnet mask The Subnet mask makes the (programmable) fieldbus
coupler or controller able to differentiate, which parts of
the IP address determine the network and which the

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
