WAGO 750 Series User Manual

Linux Fieldbus Coupler 750-860 • 53
Technical Data
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
3.11 Technical Data
System data
Number of I/O modules Limited by ETHERNET specification
Transmission medium
Twisted Pair S-UTP 100 Ω CAT 5
Buscoupler connection RJ45
Max. length of fieldbus segment
100 m between hub station and Linux_fieldbus
coupler;
max. length of network limited by ETHERNET
specification
Baud rate 10/100 Mbit/s
Protocols
MODBUS/TCP, HTTP, BootP, DHCP, DNS, SNTP,
FTP, Telnet, NFS
CPU 32-Bit-Risc ARM7/44 MHz
RAM 1 16 MByte
RAM 2 (NOVRAM) 32 kbytes
FLASH memory 4 MByte (2.69 MByte for file system)
EEPROM 4 kbytes
Standards and guidelines (see chapter 2.2 )
EMC CE Immunity to interference Acc. to EN 61000-6-2 (1999)
EMC CE Emission of interference Acc. to EN 50081-2 (1994)
Approvals (see chapter 2.2)
C
UL
US
(UL508)
C
UL
US
(UL1604) Class I Div2 ABCD T4A
DEMKO II 3 G EEx nA II T4
Conformity marking
Accessories
Miniature WSB Quick marking
system

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
