WAGO 750 Series User Manual

8 • Important Comments
Scope
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
1.6 Scope
This manual describes the Linux fieldbus coupler, item no. 750-860,
WAGO-I/O-SYSTEM 750
Item.-No. Description
750-860 Linux fieldbus coupler
1.7 Abbreviation
AI
Analog Input
AO
Analog Output
DI
Digital Input
DO
Digital Output
I/O
Input/Output
ID
Identifier
Linux-FBK
Programmable Linux fieldbus coupler

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
