WAGO 750 Series User Manual

92 • Board Support Package (BSP)
Ethernet Interface Services
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
4.6.2 Permanent Assignment of the IP Address (wagoset)
The wagoset program serves to read and write the Ethernet configuration with
the Linux console and user programs. The program only changes the Linux
kernel boot parameters that are stored in the flash memory, i.e. the changes are
only accepted after the next reboot, however, they are stored permanently.
The program is directly accessed via the console and has the following HELP
page:
Usage: ./wagoset OPTION [VALUE] ...
WAGO ETHERNET BOOT CONFIGURATION.
OPTION:
-v, --view View Configuration
-m, --mode Ethernet Mode; VALUE: static, dhcp, bootp,
none
-i, --ip Static IP; VALUE: x.x.x.x
-s, --subnet Subnet Mask; VALUE: x.x.x.x
-g, --gateway Gateway; VALUE: x.x.x.x
-o, --hostname Hostname; VALUE: [String Hostname]
-h, --help Print this message.
Proprietary.
Send bug reports to support@wago.com
To view the current settings use
./wagoset -v
To start the Linux fieldbus coupler with IP address 192.168.1.4 during the
next boot use the following command
./wagoset -m static –i 192.168.1.4 –s 255.255.255.0 –g 0.0.0.0

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
