WAGO 750 Series User Manual

84 • Board Support Package (BSP)
Ethernet Interface Services
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
4.5.3 FTP Client
The Linux fieldbus coupler incorporates an FTP client. This allows to
download files from the FTP server or to write files to the server via FTP. The
FTP client is installed in the /bin directory and can thus be used from every
directory by every user. Port 21 is used for the FTP protocol.
FTP Client Operation
In order to be able to use the FTP client, an FTP server and a user for the FTP
access must be installed on the remote PC. It is started by:
ftp <IP/hostname>
Example: ftp 192.168.1.11
The FTP server asks for user and password. You can then execute commands
on the server. What commands are supported by the server can be queried by
the command:
help.
The server shows a list with all available FTP commands.
By
help <command>
you get a description of the queried command from the server.
Example: help cd

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
