WAGO 750 Series User Manual

142 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
7.1.5 Special Modules
Tab. 7-5: Special modules
Counter Modules
750-404, 753-404 Up / down counter, DC 24 V, 100 kHz
750-638, 753-638 2 Channel, up / down counter, DC 24 V/ 16 bit / 500 Hz
Frequency Measuring
750-404/000-003,
753-404/000-003
Frequency measuring
Pulse Width Module
750-511 2-channel pulse width module, DC 24 V, short-circuit-protected,
high-side switching
Distance and Angle Measurement Modules
750-630 SSI transmitter interface
750-631 Incremental encor interface, differential inputs
750-634 Incremental encor interface, DC 24 V
750-637 Incremental encor interface RS 422, cam outputs
750-635, 753-635 Digital pulse interface, for magnetostrictive distance sensors
Serial Interfaces
750-650, 753 Serial interface RS 232 C
750-653, 753 Serial interface RS 485
750-651 TTY-Serial interface, 20 mA Current Loop
750-654 Data exchange module
DALI / DSI Master Module
750-641 DALI / DSI master module
AS interface Master Module
750-655 AS interface master module
Radio Receiver Module
750-642 Radio receiver EnOcean
MP Bus Master Module
750-643 MP bus (multi point bus) master module
Vibration Monitoring
750-645 2 Channel vibration velocity / bearing condition monitoring VIB I/O

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
