152 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
4 Channel Analog Input Modules
750-453, -455, -457, -459, -460, -468, (and all variations),
753-453, -455, -457, -459
Input Process Image
Byte Destination
Offset
High Byte Low Byte
Remark
0 D1 D0 Measured Value Channel 1
1 D3 D2 Measured Value Channel 2
2 D5 D4 Measured Value Channel 3
3 D7 D6 Measured Value Channel 4
7.2.4 Analog Output Modules
The hardware of an analog output module has 16 bits of measured analog
data per channel and 8 bits of control/status. However, the
coupler/controller with MODBUS/TCP does not have access to the 8
control/status bits. Therefore, the coupler/controller with MODBUS/TCP
can only access the 16 bits of analog data per channel, which are grouped
as words and mapped in Intel format in the Output Process Image.
When digital output modules are also present in the node, the analog output
data is always mapped into the Output Process Image in front of the digital
data.
2 Channel Analog Output Modules
750-550, -552, -554, -556, -560, -585, (and all variations),
753-550, -552, -554, -556
Output Process Image
Byte Destination
Offset
High Byte Low Byte
Remark
0 D1 D0 Output Value Channel 1
1 D3 D2 Output Value Channel 2
