Internal Bus Driver (kbus.ko)
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
6.5 Internal Bus Driver (kbus.ko)
The internal bus driver kbus is a char device driver. It is therefore possible to
access the connected I/O modules using the standard device interface. The
driver is started automatically via the /etc/startwago file when the Linux
fieldbus controller is started.
In order not to have to create definitions manually, the header file kbusapi.h
can be used in its own program. Functions that are additionally available in the
file (e.g., KbusUpdate) are no longer required and only included for
compatibility reasons.
Note:
The file kbusapi.h provides several macros that make it easier to access the
process image, however, they are not essential.
It may be beneficial to customize structures with meaningful names taken
from the control process.
Source code files:
~/uclinux-dist/user/kbusapi/kbusapi.h
Driver/Kernel module: kbus.ko (internal bus support)
Function Description
The internal bus driver can be used with the following functions:
• open(„/dev/kbus“, O_WRONLY)
Opens the kbus driver.
• ioctl(iFD, IOCTL_KBUSUPDATE, &ulTmp)
Writes the modified data of the output process image to the modules and
simultaneously reads the current data of the input modules back in.
•
ioctl(iFD, IOCTL_GETBINOUTPUTOFFSET, &ulOutputOffset)
Reads out the
Offset value. The first digital output module in the output
process image has the Offset value. It is therefore easier to access the
digital I/O modules.
• ioctl(iFD, IOCTL_GETBININPUTOFFSET, &ulInputOffset)
Reads out the Offset value. The first digital input module in the input
process image has the Offset value. It is therefore easier to access the
digital I/O modules.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
