Application Examples • 177

Example Program for a CGI Application

WAGO-I/O-SYSTEM 750

Linux Fieldbus Coupler

8.4 Example Program for a CGI Application

Program names:

web, info, ether, kernelmsg, eeprom, config, restart

Installation directory: /var/www

index.html

upperframe.html

menuframe.html

Installation directory: /var/www/cgi-bin

web

info (symbolic link web)

ether (symbolic link web)

kernelmsg (symbolic link web)

eeprom (symbolic link web)

config (symbolic link web)

restart (symbolic link web)

Source code files:

~/uclinux-dist/user/wagoweb/html/index.html

~/uclinux-dist/user/wagoweb/html/upperframe.html

~/uclinux-dist/user/wagoweb/html/menuframe.html

~/uclinux-dist/user/wagoweb/web.c

~/uclinux-dist/user/wagoweb/info.c

~/uclinux-dist/user/wagoweb/ether.c

~/uclinux-dist/user/wagoweb/kernelmsg.c

~/uclinux-dist/user/wagoweb/eeprom.c

~/uclinux-dist/user/wagoweb/config.c

~/uclinux-dist/user/wagoweb/restart.c

Function description

This example program implements the web-based management (WBM) of the

Linux fieldbus coupler.

The web server BOA uses the CGI files/programs. The HTML pages come

directly from the web server.

The CGI file web can be called via different symbolic links. The name of the

link is analyzed in the file and has a direct effect on the HTML output. The

links described above are essential in order to execute the functions. This type

of CGI call administration is ideal if you only want to need little memory in

the file system for the files to be called. It is furthermore possible to exchange

the entire functionality of the CGI calls by only replacing one file (see also

chapter 4.5.5).
