WAGO 750 Series User Manual

130 • Process Image
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
6.4 Application Example for a Mixed Node
Bit 1
Bit 4
ON
LINK
TxD/RxD
ERROR
Ethernet
750-842
I/O
WAGO
-
I/O-
SY STEM
DI
AI
Bit 1
Bit 2
AO
DO
Bit 1
USR
0x0001
0x0000
0x0002
Addresses
Process input image
(Byte)
I/O Modules 750- 402 472 501 550 600
Process output image
(Byte)
DO: Digital Output Module
AO: Analog Output Module
DI : Digital Input Module
AI : Analog Input Module
Addresses
Byte1
Byte2
Byte 3
Byte 4
Byte 2
Byte 1
Byte1
Byte2
Byte 3
Byte 4
Byte 2
Byte 1
Byte1
Byte2
Byte 3
Byte 4
Byte 2
Byte 1
0x0003
0x0004
Byte1
Byte2
Byte 3
Byte 4
Byte 2
Byte 1
0x0003
0x0001
0x0000
0x0002
0x0004
Fig. 6-3: Addressing example for a fieldbus node g086058d

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
