WAGO 750 Series User Manual

I/O Modules • 139
Overview
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
DO AC/DC 230 V
750-509, 753-509 2 Channel solid state relay, AC/DC 230 V, 300 mA
750-522 2 Channel solid state relay, AC/DC 230 V, 500 mA, 3 A (< 30 s)
DO Relay
750-523 1 Channel, AC 230 V, AC 16 A, potential-free, 1 make contact
750-514, 753-514 2 Channel, AC 125 V , AC 0.5 A , DC 30 V, DC 1 A,
potential-free, 2 changeover contacts
750-517, 753-517 2 Channel, AC 230 V, 1 A, potential-free, 2 changeover contacts
750-512, 753-512 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, non-floating, 2 make
contacts
750-513, 753-513 2 Channel, AC 230 V, DC 30 V, AC/DC 2 A, potential-free, 2 make
contacts
7.1.3 Analog Input Modules
Tab. 7-3: Analog input modules
AI 0 - 20 mA
750-452, 753-452 2 Channel, 0 - 20 mA, differential input
750-465, 753-465 2 Channel, 0 - 20 mA, single-ended
750-472, 753-472 2-Channel, 0 - 20 mA, 16 bit, single-ended
750-480 2-Channel, 0 - 20 mA , differential input
750-453, 753-453 4 Channel, 0 - 20 mA, single-ended
AI 4 - 20 mA
750-454, 753-454 2 Channel, 4 - 20 mA, differential input
750-474, 753-474 2 Channel, 4 - 20 mA, 16 bit, single-ended
750-466, 753-466 2 Channel, 4 - 20 mA, single ended
750-485 2 Channel, 4 - 20 mA, EEx i, single-ended
750-492, 753-492 2 Channel, 4 - 20 mA, isolated differential input
750-455, 753-455 4 Channel, 4 - 20 mA, single-ended
AI 0 - 1 A
750-475, 753-475 2-Channel, 0 - 1 A AC/DC, differential input
AI 0 - 5 A
750-475/020-000,
753-475/020-000
2-Channel, 0 - 5 A AC/DC, differential input

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
