WAGO 750 Series User Manual

140 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
AI 0 - 10 V
750-467, 753-467 2 Channel, DC 0 - 10 V, single-ended
750-477, 753-477 2 Channel, AC/DC 0 - 10 V, differential input
750-478, 753-478 2 Channel, DC 0 - 10 V, single-ended
750-459, 753-459 4 Channel, DC 0 - 10 V, single-ended
750-468 4 Channel, DC 0 - 10 V, single-ended
AI DC ± 10 V
750-456, 753-456 2 Channel, DC ± 10 V, differential input
750-479, 753-479 2 Channel, DC ± 10 V, differential measurement input
750-476, 753-476 2 Channel, DC ± 10 V, single-ended
750-457, 753-457 4 Channel, DC ± 10 V, single-ended
AI DC 0 - 30 V
750-483, 753-483 2 Channel, DC 0 -30 V, differential measurement input
AI Resistance Sensors
750-461, 753-461 2 Channel, resistance sensors, PT100 / RTD
750-481/003-000 2 Channel, resistance sensors, PT100 / RTD, EEx i
750-460 4 Channel, resistance sensors, PT100 / RTD
AI Thermocouples
750-462 2 Channel, thermocouples, line break detection,
sensor types: J, K, B, E, N, R, S, T, U
750-469, 753-469 2 Channel, thermocouples, line break detection,
sensor types: J, K, B, E, N, R, S, T, U, L
AI Others
750-491 1 Channel for resistor bridges (strain gauge)

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
