WAGO 750 Series User Manual

138 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
DI NAMUR
750-435 1 Channel, NAMUR EEx i, proximity switch acc. to DIN EN 50227
750-425, 753-425 2 Channel, NAMUR, proximity switch acc. to DIN EN 50227
750-438 2 Channel, NAMUR EEx i, proximity switch acc. to DIN EN 50227
DI Intruder Detection
750-424, 753-424 2 Channel, DC 24 V, intruder detection
7.1.2 Digital Output Modules
Tab. 7-2: Digital output modules
DO DC 5 V
750-519 4 Channel, DC 5 V, 20mA, short-circuit-protected; high-side switching
DO DC 12(14) V
753-534 8 Channel, DC 12(14) V, 1A, short-circuit-protected; high-side switching
DO DC 24 V
750-501, 753-501 2 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-502, 753-502 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching
750-506, 753-506 2 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching;
diagnostics
750-507, 753-507 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching;
diagnostics; no longer available, replaced by 750-508!
750-508 2 Channel, DC 24 V, 2.0 A, short-circuit-protected; high-side switching;
diagnostics; replacement for 750-507
750-535 2 Channel, DC 24 V, EEx i, short-circuit-protected; high-side switching
750-504, 753-504 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-531, 753-531 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-532 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching;
diagnostics
750-516, 753-516 4 Channel, DC 24 V, 0.5 A, short-circuit-protected; low-side switching
750-530, 753-530 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching
750-537 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; high-side switching;
diagnostics
750-536 8 Channel, DC 24 V, 0.5 A, short-circuit-protected; low-side switching
DO AC 120(230) V
753-540 4 Channel, AC 120(230) V, 0.25 A, short-circuit-protected;
high-side switching

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
