54 • Linux Fieldbus Coupler 750-860
Technical Data
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Technical data
Number of I/O modules
Number of I/O modules with bus
extension
64
250
Per node
Digital signals
Analog signals
Max. 2040 (inputs and outputs)
Max. 1020 (inputs and outputs)
Configuration possibility Via PC
Max. number of
socket connections
1 HTTP,
1 FTP,
8 Telnet,
8 NFS
Powerfail RTC buffer Min. 6 days
Voltage supply DC 24 V (-15 %/+ 20 %)
Input current
max
500 mA at 24 V
Efficiency of the power supply 87 %
Internal current consumption 300 mA bei 5 V
Total current for I/O modules 1700 mA bei 5 V
Isolation 500 V system/supply
Voltage via power jumper contacts DC 24 V (-15 % ... + 20 %)
Current via power jumper contacts
max
DC 10 A
Dimensions (mm) W x H x L 51 x 65* x 100 (*from upper edge of DIN 35 rail)
Weight Approx. 180 g

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
