134 • Process Image
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Example: how to reset a bit
The following example shows how to reset a bit:
Using the
pstPabOut->uc.Pab[0] &= ~0x08;
sample code allows you to perform a boolian AND operation with the inverted
value of 0x08 ('1111.0111') with the output process image to set the bit 0.3 to
FALSE.
Example: byte query
The following example shows how to query a byte:
Using the
if (pstPabIn->uc.Pab[0] == 38)
{
...
}
code allows you to check whether byte 0 has the value 38 by using the equal
conditional operatior.
Example: word query
The following example shows how to query a word:
Using the
if (pstPabIn->us.Pab[0] == 0x0008)
{
...
}
sample code allows you to check whether the 0-bit process array (us) has the
value 0x0008

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
