WAGO 750 Series User Manual

The WAGO-I/O-SYSTEM 750 • 11
Technical Data
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Safe electrical isolation
Air and creepage distance acc. to IEC 60664-1
Degree of pollution
acc. To IEC 61131-2
2
Degree of protection
Degree of protection IP 20
Electromagnetic compatibility
Immunity to interference for industrial areas acc. to EN 61000-6-2 (2001)
Test specification Test values Strength
class
Evaluation
criteria
EN 61000-4-2 ESD 4 kV/8 kV (contact/air) 2/3 B
EN 61000-4-3
electromagnetic fields
10 V/m 80 MHz ... 1 GHz 3 A
EN 61000-4-4 burst 1 kV/2 kV (data/supply) 2/3 B
-/- (line/line) Data:
1 kV (line/earth) 2
B
0.5 kV (line/line) 1 DC
supply:
0.5 kV (line/earth) 1
B
1 kV (line/line) 2
EN 61000-4-5 surge
AC
supply:
2 kV (line/earth) 3
B
EN 61000-4-6
RF disturbances
10 V/m 80 % AM (0.15 ... 80
MHz)
3 A
Emission of interference for industrial areas acc. to EN 61000-6-4 (2001)
Test specification Limit values/[QP]*) Frequency range Distance
79 dB (μV) 150 kHz ... 500 kHz EN 55011 (AC supply,
conducted)
73 dB (μV) 500 kHz ... 30 MHz
40 dB (μV/m) 30 MHz ... 230 MHz 10 m EN 55011 (radiated)
47 dB (μV/m) 230 MHz ... 1 GHz 10 m
Emission of interference for residential areas acc. to EN 61000-6-3 (2001)
Test specification Limit values/[QP]*) Frequency range Distance
66 ... 56 dB (μV) 150 kHz ... 500 kHz
56 dB (μV) 500 kHz ... 5 MHz
EN 55022 (AC supply,
conducted)
60 dB (μV) 5 MHz ... 30 MHz
40 ... 30 dB (μA) 150 kHz ... 500 kHz EN 55022 (DC supply/data,
conducted)
30 dB (μA) 500 kHz ... 30 MHz
30 dB (μV/m) 30 MHz ... 230 MHz 10 m EN 55022 (radiated)
37 dB (μV/m) 230 MHz ... 1 GHz 10 m

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
