146 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
2 Channel Digital Input Modules
750-400, -401, -405, -406, -410, -411, -412, -427, -438, (and all
variations), 753-400, -401, -405, -406, -410, -411, -412, -427
Input Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Data bit
DI 2
Channel
2
Data bit
DI 1
Channel
1
2 Channel Digital Input Modules with Diagnostics
750-419, -421, -424, -425, 753-421, -424, -425
Input Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Diagnostic
bit S 2
Channel 2
Diagnostic
bit S 1
Channel 1
Data bit
DI 2
Channel
2
Data bit
DI 1
Channel
1
2 Channel Digital Input Module with Diagnostics and Output Process
Data
750-418, 753-418
The 750-418, 753-418 digital input module supplies a diagnostic and
acknowledge bit for each input channel. If a fault condition occurs, the
diagnostic bit is set. After the fault condition is cleared, an acknowledge
bit must be set to re-activate the input. The diagnostic data and input data
bit is mapped in the Input Process Image, while the acknowledge bit is in
the Output Process Image.
Input Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Diagnostic
bit S 2
Channel 2
Diagnostic
bit S 1
Channel 1
Data bit
DI 2
Channel
2
Data bit
DI 1
Channel
1
Output Process Image
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Acknowledge
ment bit
Q 2
Channel 2
Acknowledg
ement bit
Q 1
Channel 1
0 0
4 Channel Digital Input Modules
