WAGO 750 Series User Manual

156 • I/O Modules
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Input and Output Process Image
Byte Destination
Offset
High Byte Low Byte
Remark
0 - C0/S0 Control/Status byte of Channel 1
1 D1 D0 Data Value of Channel 1
2 - C1/S1 Control/Status byte of Channel 2
3 D3 D2 Data Value of Channel 2
Serial Interface Modules with alternative Data Format
750-650, (and the variations /000-002, -004, -006, -009, -010, -011, -012,
-013)
750-651, (and the variations /000-002, -003)
750-653, (and the variations /000-002, -007)
Note:
With the freely parametrizable variations /003 000 of the serial interface
modules, the desired operation mode can be set. Dependent on it, the
process image of these modules is then the same, as from the appropriate
variation.
The above Serial Interface Modules with alternative data format have a
total of 4 bytes of user data in both the Input and Output Process Image
(3 bytes of serial data and 1 byte of control/status). The following table
illustrates the Input and Output Process Image, which have a total of 2
words mapped into each image. Word alignment is applied.
Input and Output Process Image
Byte Destination
Offset
High Byte Low Byte
Remark
0 D0 C/S Data byte Control/Status byte
1 D2 D1 Data bytes

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
