The WAGO-I/O-SYSTEM 750 • 13
Technical Data
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
For Products of the WAGO-I/O-SYSTEM 750 with ship specific approvals
supplementary guidelines are valid:
Electromagnetic compatibility
Immunity to interference acc. to Germanischer Lloyd (2003)
Test specification Test values Strength
class
Evaluation
criteria
IEC 61000-4-2 ESD 6 kV/8 kV (contact/air) 3/3 B
IEC 61000-4-3
electromagnetic fields
10 V/m 80 MHz ... 2 GHz 3 A
IEC 61000-4-4 burst 1 kV/2 kV (data/supply) 2/3 A
0.5 kV (line/line) 1 IEC 61000-4-5 surge AC/DC
Supply:
1 kV (line/earth) 2
A
IEC 61000-4-6
RF disturbances
10 V/m 80 % AM (0.15 ... 80
MHz)
3 A
Type test AF disturbances
(harmonic waves)
3 V, 2 W - A
Type test high voltage 755 V DC
1500 V AC
- -
Emission of interference acc. to Germanischer Lloyd (2003)
Test specification Limit values Frequency range Distance
96 ... 50 dB (μV) 10 kHz ... 150 kHz
60 ... 50 dB (μV) 150 kHz ... 350 kHz
Type test
(EMC1, conducted)
allows for ship bridge control
applications
50 dB (μV) 350 kHz ... 30 MHz
80 ... 52 dB (μV/m) 150 kHz ... 300 kHz 3 m
52 ... 34 dB (μV/m) 300 kHz ... 30 MHz 3 m
Type test
(EMC1, radiated)
allows for ship bridge control
applications
54 dB (μV/m) 30 MHz ... 2 GHz 3 m
except: 24 dB (μV/m) 156 MHz ... 165 MHz 3 m
Mechanical strength acc. to Germanischer Lloyd (2003)
Test specification Frequency range Limit value
2 Hz ≤ f < 25 Hz
± 1.6 mm amplitude (permanent)
25 Hz ≤ f < 100 Hz
4 g (permanent)
IEC 60068-2-6 vibration
(category A – D)
Note on vibration test:
a) Frequency change: max. 1 octave/minute
b) Vibration direction: 3 axes

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
