168 • Application Examples
LED Indication Example
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
The kernel module ledman serves to easily access the free LEDs from a user
program. In order to illustrate the driver interface, the Linux coupler
incorporates the leds example program that allows to changes to the state of
the LEDs via the Linux console.
The program is called directly via the console and has the following HELP
page:
Usage: ./leds OPTION [LEDNAME] [OPTION] [LEDNAME] ...
WAGO LED SERVER.
OPTION:
-n, --on Switch LED on
-o, --off Switch LED off
-f, --flash Switch LED to flashing Mode
-h, --help Print this message.
LEDNAME:
sr Status LED 1 (red)
sg Status LED 1 (green)
er Service LED 2 (red)
eg Service LED 2 (green)
ur User LED (red)
ug User LED (green)
a All LEDs
Proprietary. Send bug reports to support@wago.com
Different OPTIONS/commands can be sent to the LEDs via the example
program. The LEDs can be turned on or off or they can blink.
Each OPTION requires an LEDNAME in order to define to which LED the
OPTION/function is applied.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
