WAGO 750 Series User Manual

Glossary • 237
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
Router
Connects neighboring subnets, the router operating with addresses and
protocols of the third ISO/OSI layer. As this layer is hardware independent,
the routers allow transition to another transmission medium.
To transmit a message the router evaluates the logical address (source and
destination address) and finds the best path if there are several possibilities.
Routers can be operated as repeaters or bridges.
Routing
Method of selecting the best path over which to send data to a distant
network.
S
SCADA
Abbreviation for Supervisory Control and Data Acquisition. SCADA
software is a program for the control and visualization of processes.
Segment
Typically, a network is divided up into different physical network segments
by way of routers or repeaters.
Server
Device providing services within a client/server system. The service is
requested by the Client.
Service
Object operation (read, write).
SMTP
Short form for „Simple Mail Transfer Protocol“. Standard protocol, with
which E-mails are sent away in the internet.
SNMP
Short form for „Simple Network Management Protocol“. SNMP serves
remote maintenance of servers. Thus leave themselves e.g. rout directly from
the office of the network carrier out to configure, without someone must
drive for this to the customer.

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
