Board Support Package (BSP) 61
File System (Root File System)
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
The /bin directory
Files in the /bin directory can be run from any directory like shell commands.
This directory contains all programs that can generally be accessed. In order to
save memory resources in the file system, different programs are used that are
especially adapted to embedded systems.
The following programs are available (condition upon delivery):
busybox
Combines the common Linux console programs for system administration
tinylogin
Combines the common user administration programs
boa
Compact and safe web server
mkfs.jffs2
Used to create the JFFS2 file system in the flash memory
telnetd
Telnet server
inetd
Inet server for the connection with Telnet and FTP
ftpd
Ftp server
msntp
SNTP client to query an NTP time server
leds
Example for controlling the LEDs of the Linux fieldbus coupler (see
chapter
8)
wagoset
Example for setting/reading the Ethernet configuration in the higher flash
memory area (see chapter
4.6.2)
kbusdemo
Demo program for reading or writing process data to the IO modules (see
chapter 8)
