66 • Board Support Package (BSP)
The Console of the Linux Fieldbus Coupler
WAGO-I/O-SYSTEM 750
Linux Fieldbus Coupler
• date
Showing and setting the real time clock (RTC)
• msh
Minix shell to execute simple scripts
• cat
Shows text files
• vi
Editor to change text files
• rm
Deletes file
• ps
Shows all loaded programs in the user space
• mv
Moves files
• ls
Lists all files of the current directory
• ln
Creates links
• df
Shows file system information (free memory)
• cp
Copies files
• top
Shows the system capacity occurring through each
individual process (in %)

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
