WAHLAP TECH PUSHING POINTS - Page 38

32
TILT
E02
Error
Code
LCD
Display
Error
Meaning
Causes Way to remove
E02 TILT
Detected to tilt
(The frame has been shaken)
E01
COIN JAM ERROR
E01 COIN JAM
When the coin-sensor of the
coin-acceptor is ON for two seconds,
it cannot be turned OFF.
Take out the coins stuck in the
coin-acceptor.
Jacking-rod
Lower limit-sensor
error
E10
E10 DOWN
LIMIT
The lower limit-sensor does not
sense within 6 seconds when
the jacking-rod is about to move
downward.
It may be the moving-up/down
motor fault or lower limit-sensor
fault.
E21
E21 RIGHT
LIMIT
The right limit-sensor does not
sense within 10 seconds when
the jacking-rod is moving to the
left.
The right limit-sensor malfunctions.
Jacking-rod
Right limit-sensor
error
E22
E22 L/R SPIN
When the jacking-rod moves to
the right or left, the
moving-left/right-sensor or the
left/right limit-sensor does not
sense within 1 second.
The moving-left/right motor or the
moving-left/right-sensor or left/right
limit-sensor malfunction.
Jacking-rod
Moving-left/right
-sensor error
E30
E30 FRONT
LIMIT
The front limit-sensor does not
sense within 8 seconds when
the jacking-rod moves forward.
The front limit-sensor malfunctions.
Jacking-rod
Front limit-sensor
error
Jacking-rod
Colliding sensor
error
E12
E12 PUSHER
BUMP
The colliding sensor is detected
during which the jacking-rod is
moving upward.
The colliding sensor malfunctions.
Jacking-rod
Left limit-sensor
error
E20
E20 LEFT LIMIT
The left limit-sensor does not
sense within 10 seconds when
the jacking-rod is moving to the
left.
The left limit-sensor malfunctions.
The solution is to change
[TILT]setting.
In auto mode, the game will be
automatically restored after
sounding for 20 seconds.
In manual mode, the game will not
be automatically restored and the
error shall be remedied in order.
This error will not occur if set to
OFF.
※if the game is interrupted due to
this error, the game will be directly
cancelled and the game cannot be
continued after restarting.
Jacking-rod
Upper limit-sensor
error
E11
E11 UP LIMIT
The upper limit-sensor or
colliding-sensor do not sense
within 6 seconds when the
jacking-rod is moving upward.
1. It may be the moving-up/down
motor fault or upper limit-sensor
fault.
2. It may be that the screw on the
moving-up/down motor is screwed
too tightly to result in too little
pressure on the wheel and the
jacking-rod cannot rise.(please
refer to the sections on P52
"5.2.21" for how to adjust the
jacking-rod).
3. There may be oil-slick on the
jacking-rod, which needs to be
cleaned.
4. Check whether the jacking-rod is
blocked when rising.
