WAHLAP TECH PUSHING POINTS - Page 39

Moving-left/right motor
E 22 & E 21 & E 20
Front limit-sensor
E 30
Bank limit-sensor
E 31
Moving-forward
/backward-sensor
E 32
33
Lower limit-sensor E 10
Left limit-sensor
E 20
Left/right limit-sensor
E 22
Moving-up/down
motor
E 11 & E 110
Moving-forward/backward
motor
E 32 & E 31 & E30
E 21
Right limit-sensor
Upper limit-sensor E 11
Colliding sensor E 12
E31 E31 BACK LIMIT
The bank limit-sensor does not
sense within 8 seconds when the
jacking-rod moves backward.
The bank limit-sensor malfunctions.
Jacking-rod
Bank limit-sensor
error
E32
The moving-forward/backward
motor, the moving-forward/
backward sensor and limit
sensor malfunction.
E32 F/B SPIN
When the jacking-rod moves
forward, the moving-forward/
backward sensor or limit-sensor
do not sense within 1 second.
Jacking-rod
Moving-forward/backward
-sensor error
Error
Code
LCD
Display
Error
Meaning
Causes Way to remove
COIN JAM ERROR
E 01
