Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023
107
INSTALLER MENU FUNCTIONS
Table 6. SmartDC Controller - Installer Menu Funcons
Ref.
No�
Installer Menu Seng Opons
(Bold = Factory Sengs) Menu Tasks and Explanaons
Associated
DC Controller
Connecons
Display
5
MN 0
MODEL NUMBER
0 = model type unknown
1 = Model <x>
2 = Model <x>
Select the type of gate operator model
used at the site. This menu item is used
when changing a circuit board.
Note: This menu item only appears,
if applicable, when you set the OT
(operator type).
(N/A)
6
WT 0
GATE WEIGHT (LB)
0 = Gate disabled
DC 15 DC 10F
0-400 lbs 0-250 lbs
401-800 lbs 251-500 lbs
801-1100 lbs 501-750 lbs
1101-1500 lbs 751-1000 lbs
Select the gate’s weight range in pounds.
The installer must designate the gate’s
weight before the operator will funcon.
See “Programming the Inial Setup
Menu” on page 61. Designang the
correct gate weight allows the operator to
determine the appropriate acceleraon
and deceleraon rates.
(N/A)
7
OS 1
OPEN SPEED
DC 15 DC 10F
0 = 0.75/s 4 = 1.75/s
1 = 1.0/s 5 = 2.0/s
2 = 1.25/s 6 = 2.25/s
Designate how quickly the gate opens.
The opons available dier depending
on the Operator Type (OT). Kinec has
two operator types: OT15 ≤ 1.25/s and
OT16 ≥ 1.75/s. Sengs higher than 1 are
reserved for Usage Class 3 and 4.
Note: Kinec DC15 [Kinec 1] = OT 15
and Kinec DC10F [Kinec 2] = OT16.
(N/A)
8
CS 1
CLOSE SPEED
DC 15 DC 10F
0 = 0.75/s 4 = 1.75/s
1 = 1.0/s 5 = 2.0/s
2 = 1.25/s 6 = 2.25/s
Designate how quickly the gate closes.
The opons available dier depending
on the Operator Type (OT). Kinec has
two operator types: OT15 ≤ 1.25/s and
OT16 ≥ 1.75/s. Sengs higher than 1 are
reserved for Usage Class 3 and 4.
Note: Kinec DC15 [Kinec 1] = OT 15
and Kinec DC10F [Kinec 2] = OT16.
(N/A)
9
FD 0 (OFF)
FACTORY DEFAULTS
0 = user sengs
1 = reload factory default
sengs
Globally restores all menu sengs back
to new operator status. Select seng 1 to
return the operator to factory defaults.
Note: If factory defaults are restored, the
UL usage class, handing, gate weight and
any other modied menu sengs will
need to be congured again.
(N/A)
