INSTALLER MENU FUNCTIONS
Table 6. SmartDC Controller - Installer Menu Funcons
Ref.
No�
Installer Menu Seng Opons
(Bold = Factory Sengs) Menu Tasks and Explanaons
Associated
DC Controller
Connecons
Display
19
RT 0 (80 SECS)
MAXIMUM RUN TIMER
Not used in Kinec
operators.
-- (N/A)
20
PO 0 (OFF)
PARTIAL OPEN
0 = OFF
7 = 7 ., 8 = 8 ., through
32 = 32 .
Sets the distance (from the closed gate
posion) where the gate stops in a
paral open. When a number is entered
in the PO display, the open paral input
becomes operaonal.
OPEN PARTIAL
COM
21
EC 0 (STOP ONLY)
EYE CLOSE LOGIC
0 = Close eye stops only
1 = 2s reverse to open
2 = Full Open
The default seng is non-reversal if the
close photo eye is triggered. A seng of
1 causes the gate to reverse and travel
open for two seconds if triggered while
closing. A seng of 2 reverses the gate to
full open.
Sensor
Common
Sensor Input
22
EO 0 (STOP ONLY)
EYE OPEN LOGIC
0 = Open eye stops only
1 = 2s reverse to close
The default seng is non-reversal if the
open photo eye is triggered. A seng of
1 causes the gate to reverse travel and
close for two seconds if triggered while
opening.
Sensor
Common
Sensor Input
23
GC 1 NC CONTACT
GATE EDGE OUTPUT
0 = Normally Open Edge
1 = Normally Closed
This menu item only appears when UC
is set to 4. Default seng is edge sensor
with Normally Closed (NC) output.
Oponal seng of 0 requires an (NO)
output.
Sensor
Common
Sensor Input
24
GR 0 (FULL OPEN)
GATE EDGE LOGIC
0 = Edge reverses full
open
1 = 2s reversal only
The default seng is a full-open reversal
if the gate edge is triggered while closing.
The oponal seng of 1 causes the gate
to reverse for 2 seconds if triggered while
closing.
Sensor
Common
Sensor Input
25
SR 1 REVERSE 2S
IES SENSOR LOGIC
0 = IES reverses full open
1 = 2 second reversal only
The default seng is a two-second
duraon reversal if the inherent sensor
is triggered. The oponal seng of 0 will
cause the gate to reopen fully if triggered
while closing.
N/A
