Alpha/Delta (Kinetic Operator) Installation and Maintenance Manual Revision 1 - MAY 2023
133
USER RELAYS - PROGRAMMING PROCEDURE
Table 9. User-Programmable User Relays - Funcon Opons
No� Name Descripon
41 Test Open Pulse Output pulses ve seconds aer close limit is acvated. Typically
used for cycle tesng.
42 Break-Away Switch
output
Acvates when the arm break-away switch is tripped.
43 Warn Before Combinaon of relays #5 and #16.
44 Paral Open Limit Pulse Pulses for 250ms when the gate, commanded with Paral Open
input, reaches Paral Open Limit, or, the gate is past Paral Open
Limit and Paral Open input is acvated.
45 Outside Obstrucon/
Arming Loop Detector
Acvated when OOLD/OALD detector input tripped and gate
closed. Used for tesng purposes.
