Wieland samos PRO COMPACT - Diagnostics and troubleshooting

EtherNet/IP gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
109
Diagnostics and troubleshooting
1127412619
Notifications via network
1127414155
1127415691
Explicit Message Connection
Device Status is available by reading Class 1, instance 1, attribute 5. Vendor specific interface
for alarms and diagnostic for Explicit Message Connections is defined as follows:
Presence of process alarm can be detected by reading class 29, instance 1, attribute 5 and
class 30, instance 1, attribute 5. The module mode (
Run
or another state) has to be checked,
because the alarm bit is set to 0 = OK every time the module is not in
Run
mode.
The module mode can be detected by reading class 120 Instance 5 Attribute 1.
The presence of module diagnostic events can be detected by reading class 120 Instance 6 At-
tribute 1.
Detailed reasons for process alarms and system diagnostic events can be found out by reading
all 60 attributes of Class 120 Instance 3 which contains the dedicated system status bytes.
1127417227
Implicit Message Connection
If assembly instance 57 is used, Bit 6 and 7 of Byte 66 signal a process alarm when set.
If assembly instance 167 is used, Bit 6 and 7 of Byte 66 signal a process alarm when set. Bit 5
signals diagnostic events or process alarms when set.
Event details can be queried by Explicit Message requests as described here:
Explicit Mes-
saging [ch. 8.6.1, p. 106]
LED States
1127418251
1127419787
MS (Module Status)
The SP-COP2-ENI module possesses a two-color (red/green) LED with the designation
MS
.
This is the
Module Status Indicator
.
The Module Status Indicator is
dark , if no power supply is connected. It flashes green if the
device has not been configured. It turns green if the device is running correctly. It flashes
green/red
if the device is performing a switch-on test.
The Module Status Indicator
flashes red if EtherNet/IP is activated and the device has detected
a serious, eliminable error. A faulty project file or one which does not match the hardware is
classified as a serious, eliminable error. The display
turns red if EtherNet/IP is activated and the
device has detected a serious, non-eliminable error and there is a
Critical Fault
.
Table 63: MS-LED state (Selection)
Project file
System mode
Ext. Error
MS-LED state
Doesn’t matter
Switch on
Doesn’t matter
Green -> Red
Deleted
Init
Doesn’t matter
Flashing green
Invalid
Init
Doesn’t matter
Flashing red
Valid
Idle mode
Doesn’t matter
Flashing green
Valid
Run
No
Turns green
Valid
Run
Yes
Turns green/red or flashes red
Valid
Critical error
Doesn’t matter
Turns red
