Supported CIP Objects
1127347083
Identity Object
1127348619
The identity object is required for all EtherNet/IP-based products. Instance 1, attribute 1 stands
for the Vendor ID. Wieland Electric GmbH is listed by the ODVA using the value 314.
Instance 1, attribute 2 stands for the device types. The Open Type Code 0x07 stands for a
discrete universal I/O device.
Instance 1, attribute 3 stands for the product code. It is of the type UNIT and thus comprises 2
bytes.
The decimal value 1320 is derived from the article number R1.190.1320.0.
Instance 1, attribute 4 stands for the revision, that means the main and supplementary firmwa-
re version of the SP-COP2-ENI version, which you can find in the samosPLAN5+ software as
the
diagnostics version
in the
Hardware
view and as the
firmware version
in the
Gateways
view.
Instance 1, attribute 5 standard for the current state of the overall device. The data range is lis-
ted in the
Device state values table in class 1, instance 1, attribute 5 [ch. 8.4.1, p. 85] .
Instance 1, attribute 6 stands for the serial number of the device, which can be found under
the hardware configuration in samosPLAN5+. Instance 1, attribute 7 stands for the product
name SP-COP2-ENI.
Table 36: Overview of the identity class (0x01) supported by the SP-COP2-ENI module
Class
Instance
Attribute
Access
Data type
Description
Data range
1
0 = Class
1
Read
UINT
Revision
1
1 0 = Class 2 Read UINT Max. instance 1
1
0 = Class
3
Read
UINT
Number of instances
1
1 0 = Class 6 Read UINT Max. class attribute ID 7
1
0 = Class
7
Read
UINT
Max. instance attribute ID
7
1
1
1
Read
UINT
Vendor ID
314 = 0x13a
1
1
2
Read
UINT
Device type
0x07
1 1 3 Read UINT Product code [ch. 8.4.8.3, p.
97]
1320
1 1 4 Read USINT[2] Revision, software version
The “left” byte is the main
section and is transmitted
first
{1, 1} to {99, 99}
1
1
5
Read
WORD
Device state
See next table
1 1 6 Read UDINT Serial number 16010001 to
99539999
1 1 7 Read SHORT_
STRING
Product name SP-COP2-ENI
