Installation and basic configuration
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
Installation and basic configuration
910753163
Installing/removing
910754699
Installing modules on standard rail
888512651
This is only for switchboxes with protection class IP 54 or higher!
The samosPRO system is only suitable for installations in a switchbox having at least protec-
tion class IP 54.
Info
• Basic safety
Gateways must not be removed or added when the operating voltage is switched on.
• Grounding
The DIN rails must be conductively connected to the protective conductor (PE).
• ESD protection measures
Note the suitable ESD protection measures during installation.
Failure to do so could result in damage to the bus (internal safety bus).
• Protect connector openings
Undertake suitable measures so that no foreign bodies can penetrate connector openings,
particularly those for the program removable storage.
• Module width:
The modules are placed in a mounting box that is 22.5 mm or 45 mm wide depending on
type.
• Quality of standard rail
The mounting boxes are suitable for 35-mm standard rails as per EN 60715.
• Sequence of modules:
The SP-COPx controller module is inserted all the way to the left in a samosPRO system.
The two optional gateways follow directly to the right next to the controller module.
• Save space for subsequent model replacement
The modules are connected via the plug connection integrated into the housing. Note that
the samosPRO modules must be pulled about 10 mm apart for a module replacement be-
fore the corresponding module can be removed from the standard rail.
• Standards to be considered
Installation according to EN 50274
