EtherNet/IP gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
EtherNet/IP gateway
1135728779
This chapter describes the "EtherNet/IP-Gateway" function of the SP-COP2-ENI module.
The EtherNet/IP protocol is not described in this chapter. If you have little or no experience
with this, please refer to the ODVA documentation for more information. Some content can be
found in the glossary (see
Abbreviations and Definitions [ch. 1.5, p. 11]
).
Use of the term “Device” in this chapter
This chapter uses the term “Device” as a synonym for the controller module SP-COP2-ENI.
Interfaces and operation
1143906571
Interfaces and operation are identical to that of the Modbus TCP Gateway.
Read the following section:
Interfaces and operation [ch. 6.1, p. 49]
Datasheet
1127319947
The SP-COP2-ENI module supports EtherNet/IP from product version D-01.01. The following
functions are integrated:
• Implicit message transmission (transport class 1)
• Explicit message transmission (transport class 3, connected)
• Device profile: Discrete universal I/O device
• UCMM Message Server (no connection)
• Supported objects: Message router, connection manager, port, identity, Ethernet link,
TCP/IP, I/O point and group (discrete), vendor class 0x78, assembly
• Up to five simultaneous encapsulation sessions (input and output)
• Assemblies of a variable size
• Supported addressing: Class/instance/attribute and symbol tag
• Agreement with CIP (Common Industrial Protocol) specification, Version 3.18, and with
EtherNet/IP CIP specification, Version 1.19
• Details EDC file with ODVA conformity test
• Supported PCCC commands: Read and write word range, read and write input, read and
write protected logic input with two and three address fields for connection to PLC 3, PLC
5, PLC 5/250, PLC 5/VME, SLC 500, SLC 5/03, SLC 5/04 and MicroLogix-1000
• Automatic configuration of semi and full duplex connections as well as of connections
with 10 and 100 Mbit/s.
• MS (module state) and NET (network) LED
