EtherNet/IP gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
4 138 3 Read,
write
BYTE[40]
Bits of the logic outputs [ch. 8.5.2,
p. 103]
(Instance 81 to 400 of Class
See
1)
4 139 3 Read,
write
BYTE[30]
Bits of the logic outputs [ch. 8.5.2,
p. 103]
(Instance 161 to 400 of
See
1)
4 140 3 Read,
write
BYTE[20]
Bits of the logic outputs [ch. 8.5.2,
p. 103]
(Instance 241 to 400 of
Class 9)
See
1)
4 141 1 Read UINT Number of members 0
4 141 3 Read,
write
BYTE[10]
Bits of the logic outputs [ch. 8.5.2,
p. 103]
(Instance 321 to 400 of
Class 9)
See
1)
4 167 3 Read BYTE[112] Bits of the logic inputs, mode and
state bytes
(
More [ch. 8.5.3.2, p. 104]
)
See
1)
1)
See: Table
Overview of assembly databytes of the SP-COP2-ENI module [ch. 8.5.1, p. 101]
Discrete Input Point Object
1127350667
The discrete input point objects are part of the device profile
Discrete universal I/O device.
If an error occurs at the terminal input of a specific instance between 401 and 528 and the SP-
COP2-ENI module is in
mode, the value of the instance attribute 4 equals 1. In all other
cases, the value equals 0.
Table 39: Overview of the discrete input point objects (0x08) supported by the SP-COP2-ENI module
8 0 = Class 3 Read UINT Number of instances 400 + 128 +
56
Logic + input
Max. instance attribute ID
8 1 to 400
and 529 to
1 Read USINT Number of attributes 3
List of support attributes
List of support attributes
