Wieland samos PRO COMPACT - Page 87

EtherNet/IP gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
87
Class
Instance
Attribu-
te
Access
Data type
Description
Data range
8 1 to 400 3 Read BOOL The value of the input bit, configured
by the
output data set 1
in samos-
PLAN5+, stands for the data transfer-
red by the logic of the controller
module to the PLC.
0 = Off,
1 = On
8
1 to 400
4
Read
BOOL
State of output data set 1
0 = OK
8 401 to 416 3 Read BOOL Value of terminals I1 to I16 of the SP-
COP2-ENI module
0, 1
8 401 to 416 4 Read BOOL State of terminals I1 to I16 of the SP-
COP2-ENI module
0, 1
8 417 to 420 3 Read BOOL Value of terminals IQ1 to IQ4 of the
SP-COP2-ENI module when configu-
red as an input
0, 1
8 417 to 420 4 Read BOOL State of terminals IQ1 to IQ4 of the
SP-COP2-ENI module when configu-
red as an input
0, 1
8
421 to 430
3
Read
BOOL
Reserved
0
8 431 3 Read BOOL Value of B1 Voltage is...
0 = Outside
the tolerance
1 = Within
the tolerance
8 432 3 Read BOOL Value of B2 Voltage is...
0 = Outside
the tolerance
1 = Within
the tolerance
8 421 to 432 4 Read BOOL Reserved 0
8 425 + 8 x n
to
432 + 8 x n
3 Read BOOL Value of terminals I1 to I8 of the SP-
SDI[n] / SP-SDIO[n] module,
with n = 1 to 12
0, 1
8 425 + 8 x n
to
432 + 8 x n
= 528
4 Read BOOL State of terminals I1 to I8 of the SP-
SDI[n] / SP-SDIO[n] module,
where n = 1 to 12
0, 1
8 529 to 532 3 Read BOOL Value of terminals Q1 to Q4 of the
SP-COP2-ENI module
0, 1
8 533 to 536 3 Read BOOL Value of terminals IQ1 to IQ4 of the
SP-COP2-ENI module when configu-
red as an output
0, 1
8 533 + 4 x n
to
536 + 4 x n
= 584
3 Read BOOL Value of terminals Q1 to Q4 of the
SP-SDIO[n] module,
where n = 1 to 12
0, 1
