Wieland samos PRO COMPACT - Link; ACT (Activity Status)

EtherNet/IP gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
111
Error
Possible cause
Possible remedy
The SP-COP2-ENI module
does not provide any data.
• The samosPRO system is
in the stop state.
• Start the CPU (change to Run
mode).
LED PWR
Green
LED LINK
Green
LED /ACT
Yellow
MS LED
Green (1 Hz)
The SP-COP2-ENI module
does not provide any data.
• The IP address for the SP-
COP2-ENI module is as-
signed by a DHCP server.
Following a restart of the
SP-COP2-ENI module or
the DHCP server, another
address was allocated to
the SP-COP2-ENI module,
which is unknown to the
PLC.
• Either assign the SP-COP2-
ENI module a permanent IP
address or reserve a perma-
nent IP address for the the
SP-COP2-ENI module in the
DHCP server (manual as-
signment using the MAC
address of the SP-COP2-ENI
module).
LED
PWR/EC
Green
LED LINK
Green
LED /ACT
Yellow
MS LED
Green
The SP-COP2-ENI / the
samosPRO system is in
the “Critical error” state.
• The SP-COP2-ENI module
is not properly connected
to the samosPRO mo-
dules.
• The module connection
plug is dirty or damaged.
• Another samosPRO mo-
dule has an internal criti-
cal error.
• Insert the I/O module cor-
rectly. Clean the connection
plug and socket.
• Switch on the power supply
again.
• Check the other samosPRO
modules.
1127422859
LINK
The SP-COP2-ENI module possesses a green LED with the designation
LINK
. If there is no
Ethernet connection, it stays dark. If there is a connection, it switches on.
1127424395
ACT (Activity Status)
The SP-COP2-ENI module possesses a green LED with the designation
ACT
. If no port activity
can be detected, it stays dark. If port activity is detected, it switches on.
8.9.2.3
8.9.2.4
