Wieland samos PRO COMPACT - Data Set 1

EtherCAT Gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
176
Data set 1
1065963019
Data set 1 (50 bytes) contains the process data. It can be compiled with the aid of samos-
PLAN5+. In the form in which it is delivered, the content of data set 1 is preconfigured; it can
be freely modified.
Note:
Not allocated
means that the byte value is equal to 0x00. However, the user can freely
assign these bytes.
Table 117: Data set: Output data set 1 samosPRO COMPACT to --> SP-EN-ETC
Output data block 1
Output data block 2
Byte 0
Input values for Module 0 (I1..I8)
Byte 10
Not allocated
Byte 1 Input values for Module 0 (I9..I16) Byte 11 Not allocated
Byte 2
Input values for Module 0 (IQ1..IQ4)
Byte 12
Input values for Module 1
Byte 3 Output values for Module 0 (Q1..Q4,
IQ1..IQ4)
Byte 13 Input values for Module 2
Byte 4
Not allocated
Byte 14
Input values for Module 3
Byte 5
Not allocated
Byte 15
Input values for Module 4
Byte 6 Not allocated Byte 16 Input values for Module 5
Byte 7
Not allocated
Byte 17
Input values for Module 6
Byte 8
Not allocated
Byte 18
Input values for Module 7
Byte 9
Not allocated
Byte 19
Input values for Module 8
Output data block 3
Output data block 4
Byte 20
Input values for Module 9
Byte 30
Output values for Module 7
Byte 21
Input values for Module 10
Byte 31
Output values for Module 8
Byte 22
Input values for Module 11
Byte 32
Output values for Module 9
Byte 23
Input values for Module 12
Byte 33
Output values for Module 10
Byte 24
Output values for Module 1
Byte 34
Output values for Module 11
Byte 25
Output values for Module 2
Byte 35
Output values for Module 12
Byte 26
Output values for Module 3
Byte 36
Not allocated
Byte 27
Output values for Module 4
Byte 37
Not allocated
Byte 28
Output values for Module 5
Byte 38
Not allocated
Byte 29
Output values for Module 6
Byte 39
Not allocated
Output data block 5
Byte 40
Not allocated
Byte 41
Not allocated
Byte 42
Not allocated
Byte 43
Not allocated
Byte 44
Not allocated
Byte 45
Not allocated
Byte 46
Not allocated
Byte 47
Not allocated
Byte 48
Not allocated
Byte 49 Not allocated
Total
length
50 bytes
11.5.1
