Wieland samos PRO COMPACT - Canopen Gateways; Technical Data for Supply Circuit

Technical data
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
193
CANopen gateways
910883723
Interface
Minimal
Typical
Maximum
Field bus CANopen DS-301
Interface level
RS-485
Connection technology 5-pin "open style" socket
Slave address (set via
rotary switch)
0 99
Slave address (set in
samosPLAN5+
1)
1 127
Baud rate (kbits/s with
standard line)
Maximum line length
125
500 m
250
250 m
500
100 m
800
40 m
1000
20 m
Line parameters
see CANopen gateway [ch. 10, p. 129]
1)
To set the slave address via software, the hardware address setting must be "0".
Technical data for supply circuit
910884747
These technical data apply to all gateway modules.
Supply circuit
(e.g. via SBUS+)
Minimal
Typical
Maximum
Supply voltage
16.8 V DC
24 V DC
30 V DC
Power consumption
2.4 W
12.4
12.5
