Discrete Output Group Object
1127354763
The discrete output group objects are part of the device profile
Discrete universal I/O device.
The object of class 30 plays a role with regard to the alarm bit. It collects the process alarms of
all the output terminals of a SP-COP2-ENI or SP-SDIO module in one bit. If an error occurs at at
least one output terminal and the SP-COP2-ENI module is in
Run
mode, the value of the attri-
bute 5 of instance 1 equals 1. If the SP-COP2-ENI module is in
Critical error
mode, the attribu-
te value is also 1. In all other cases, the value equals 0.
Table 42: Overview of the discrete output group object (0x1D) supported by the SP-COP2-ENI module
Class
Instance
Attribute
Access
Data type
Description
Data range
30
0 = Class
1
Read
UINT
Revision of the class
1
30
0 = Class
2
Read
UINT
Max. instance
1
30
0 = Class
3
Read
UINT
Number of instances
1
30
0 = Class
6
Read
UINT
Max. class attribute ID
7
30
0 = Class
7
Read
UINT
Max. instance attribute ID
6
30
1
1
Read
USINT
Number of attributes
6
30
1
2
Read
USINT[6]
List of support attributes
{1, 2, 3, 4, 5, 6}
30
1
3
Read
USINT
Number of bound instances
56
30
1
4
Read
UINT[56]
Bound instances
{1, ..., 56}
30 1 5 Read BOOL Group state of all output terminals
(state of instances 529 to 584 of
class 8)
0 = No error,
1 = Error
