Technical data
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
192
Technical data
910881163
Modbus TCP, PROFINET IO and EtherNet/IP gateway
915628427
Use the SP-COP2-ENI controller module for the Modbus TCP, PROFINET IO and EtherNet/IP
functionalities.
You will find the technical data for this module here:
Hardware manual, chapter "Controller module"
EtherCAT gateway
1062781067
Interface
Minimal
Typical
Maximum
Field bus
EtherCAT
Connection technology
RJ45 socket
Transfer rate
100 Mbit/s (100 Base-TX)
Device type
EtherCAT slave
Data length: Inputs
50 bytes from EtherCAT to samosPRO COMPACT
Data length: Outputs
142 bytes (50 + 32 + 60) from samosPRO COMPACT to EtherCAT
Galvanic isolation
Yes - between EtherCAT (RJ45) and system voltage
Type of insulation
Function insulation
Field bus
EtherCAT
PROFIBUS DP
910882699
Interface
Minimal
Typical
Maximum
Field bus
PROFIBUS-DP-V0
Interface level
RS-485
Connection technology
9-pin D-sub socket
Slave address (set via
rotary switch)
0 99
Slave address
(set in samosPLAN5+
1)
3 125
Baud rate (automatic
adaptation)
12 MBaud
Baud rate (kbits/s with
standard line)
Maximum line length
9.6/19.2/93.75
1200 m
187.5
1000 m
500
400 m
1.500
200 m
12.000
100 m
Line parameters
see PROFIBUS-DP gateway [ch. 9, p. 114]
1)
To set the slave address via software, the hardware address setting must be "0".
