Installation and basic configuration
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
Removing modules from normal rail
888517003
Step 1: Removing a controller module
Deenergize the samosPRO system.
Remove plug-in terminals with wiring and remove the end terminal.
If expansion mode or gateways are used:
Slide the controller module in the direction of the arrow until the lateral plug connection is
disconnected.
Unlock the module.
To do this, pull the snap-on foot of the module outward using a screwdriver.
