Data transferred into the network
1065932171
Available data
The samosPRO EtherCAT gateway can provide the following data:
• Operating data
–
Logic results from the
samosPRO (see Routing Table [ch. 5.1.2, p. 37] )
–
Input values
(HIGH/LOW) for all samosPRO input expansion modules in the system
–
Output values
(HIGH/LOW) for all samosPRO input/output expansion modules (see
Module state / input and output values [ch. 3.3.1, p. 22] )
–
Output data
from another network, i.e. data received from a second gateway in the
samosPRO system (see Transmission of data from a second network [ch. 3.3.3, p. 23] )
• Diagnostics
–
Test values
(CRCs) (see Configuration test values (CRCs) [ch. 3.3.4, p. 23] )
–
Error and state information
for all modules (see Error and state information for mo-
dules [ch. 3.3.5, p. 23] )
Data sets
The physical samosPRO modules are not presented as typical hardware modules in the net-
work. Instead, the data provided by the samosPRO system have been arranged in three input
data sets.
