Wieland samos PRO COMPACT - Page 169

EtherCAT Gateway
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
169
LED
Meaning
ECAT-OUT
LINK
Off
No EtherCAT device connected, no connection
Green
On
EtherCAT device is connected
Green
Blink
The device sends/receives Ethernet frames
TX/RX
Off
This LED is not used
Table 115: Information about the light behavior of the EtherCAT status LEDs
LED states
Description
On
The indicator is constantly on.
Off
The indicator does not come on.
Blink The indicator is switched on or off in phases at a frequency of 2.5 Hz.
Single flash The indicator shows one short flash (200 ms) followed by a longer off
phase (1000 ms).
Double flash The indicator shows a sequence of two short flashes (200 ms each)
interrupted by a short off phase (200 ms).
The sequence is finished by a long off phase (1000 ms).
