Configuration of gateways
Wieland Electric GmbH | BA000970 | 11/2016 (Rev. F)
43
Modbus TCP
PROFIBUS DP
Byte
Preset allocation
Initial data
set
Preset allocation
Initial data
block
13
Inputs for Module 2
#1
(50 bytes)
Inputs for Module 2
(12 bytes)
14
Inputs for Module 3
Inputs for Module 3
15
Inputs for Module 4
Inputs for Module 4
16
Inputs for Module 5
Inputs for Module 5
17
Inputs for Module 6
Inputs for Module 6
18
Inputs for Module 7
Inputs for Module 7
19
Inputs for Module 8
Inputs for Module 8
20
Inputs for Module 9
Inputs for Module 9
21
Inputs for Module 10
Inputs for Module 10
22
Inputs for Module 11
Inputs for Module 11
23
Inputs for Module 12
Inputs for Module 12
24
Outputs for Module 1
Continued
#1
(50 bytes)
Outputs for Module 1
#3
(12 bytes)
25
Outputs for Module 2
Outputs for Module 2
26
Outputs for Module 3
Outputs for Module 3
27 Outputs for Module 4 Outputs for Module 4
28
Outputs for Module 5
Outputs for Module 5
29 Outputs for Module 6 Outputs for Module 6
30
Outputs for Module 7
Outputs for Module 7
31
Outputs for Module 8
Outputs for Module 8
32
Outputs for Module 9
Outputs for Module 9
33 Outputs for Module 10 Outputs for Module 10
34
Outputs for Module 11
Outputs for Module 11
35 Outputs for Module 12 Outputs for Module 12
36-47 Not allocated Continued
#1
(50 bytes)
Not allocated #4
(12 bytes)
48-49 Not allocated Not allocated #5
(2 bytes)
The preset allocation of the bytes can be freely configured, as shown in the following section.
