WinGD X72 - Engine Control System

Operation
4002−1/A1
Winterthur Gas & Diesel Ltd.
1/ 22
1
Engine Control System
1. General 1..........................................................
2. System Description 2...............................................
2.1 Power Supplies 7.............................................
2.2 Installation on the Engine 7....................................
2.3 Redundancy 7................................................
3. Engine Control System − Functions 8................................
3.1 Starting Valve Control 8.......................................
3.2 Servo Oil Pressure Control 9..................................
3.3 Exhaust Valve Control 10.......................................
3.4 Cylinder Lubricating Control 11.................................
3.5 Engine Speed and Crank Angle Sensor 13.......................
3.6 Crank Angle Determination Algorithm (ADA) 14..................
3.7 Diesel Fuel Pressure Control 16.................................
3.8 Diesel Fuel Injection Control 18.................................
4. External Control Systems 20.........................................
4.1 Communication between ECS and External Systems 20..........
4.2 Propulsion Control System 20..................................
4.3 Alarm and Monitoring System 21................................
1. General
The engine control system (ECS) is an embedded system that has a modular design.
Some parts and functions in the ECS configuration are optional and are related to the
application.
Note: The name of the WinGD engine control system is Unified Controls
Flex (UNIC−flex)
The system uses modern bus technologies for the transmission of signals.
Data buses transmit signals between the external systems:
D Propulsion Control System (PCS) (see paragraph 4.2)
D Alarm and Monitoring System (AMS) (see paragraph 4.3).
These data buses are the interface between the operator and engine control.
CAUTION
Damage Hazard: Software updates must be done only with the
supervision of a Wärtsilä service engineer and in accordance with
regulations that Wärtsilä Services Switzerland Ltd. has set.
Damage to the control system and the engine can occur.
