WinGD X72 - Cylinder Lubricating System − Control; Control System

Operation7218−1/A1
Winterthur Gas & Diesel Ltd.
10/ 12
8. Cylinder Lubricating System − Control
8.1 Control System
The cylinder lubricating system (see Fig. 6) is a time−based system, which supplies
lubricating oil on to the cylinder liner wall.
For more data about the cylinder lubricating control, see 4002−1 Engine Control
System, paragraph 3.4 Cylinder Lubricating Control.
DATA FOR
6 CYLINDERS
CCM-20
Cyl. 1
CCM-20
Cyl. 2
CCM-20
Cyl. 3
CCM-20
Cyl. 4
CCM-20
Cyl. 5
CANBus
CCM-20
Cyl. 6
4/2-way
Solenoid
Valve
Cylinder
Lube Oil
Tank
Duplex
Filter
Lubricating
Pump
PT3124A
PT3131C PT3136C
Lubricating
Pump
CV7131C CV7136C
Fig. 6: Control System
2015-03
Cylinder Lubrication
