WinGD X72 - 4325-1;A1

Operation4325−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
SA
9
1
2
3
45
IP
67
8
11
12
13
CA
I
I
TV
10
15
14
WCH02229
Fig. 1: Starting Air Shut-off Valve
1 Control valve 12 Double check valve 35-115HA
2 Spindle 13 Solenoid Valve CV7013C
3 Handwheel 14 Lever
4 Spring 15 Proximity sensor ZS5018C
5 Valve
6 Balance bore
7 Non-return valve IP Inlet pipe
8 Inlet chamber SA To starting air supply pipe and
9 Valve space valves 30-2728_CX_1 to CX_#
10 Pressure switch PS5017C CA Control air
11 Solenoid Valve CV7014C TV To test valve
Shut-off Valve Starting Air
2016−11
