WinGD X72 - 2303-1;A1; Piston Rod Gland

Operation2303−1/A1
Winterthur Gas & Diesel Ltd.
2/ 2
II
WCH02292
1
2
11
3
SS
BDBD
6
8
5
9
10
12
7
13
4
Fig. 2: Piston Rod Gland
1 Oil bore 10 Gasket (4-part)
2 Relief passage 11 Tension spring
3 Neutral space 12 Scraper ring (4-part)
4 Ring support (3-part) 13 Housing (2-part)
5 Support
6 Cylinder jacket
7 Scraper ring (3-part)
8 Tension spring BD Bearing oil drain
9 Gasket (four-part) SS Scavenge space
Piston Rod Gland
2015-03
